Qingdao Wanguo Sanchuan Fiber Technology Co., Ltd
Add to Cart
| Attribute | Value |
|---|---|
| Product Type | Carbon Fiber Fabric |
| Raw Material | 12K carbon yarn |
| Tensile Strength | ≥3,500 MPa |
| Tensile Modulus | 230 GPa |
| Fiber Content | ≥67% |
| Width Range | 100mm-500mm/Personalize |
Epoxy-compatible unidirectional tapes deliver 95% strength concentration in the primary fiber direction, achieving tensile strength ≥3,500 MPa (3x steel at 1/5 weight). Engineered for concrete reinforcement and composite layups, they enable rapid structural upgrades without heavy machinery.
| Product Code | Areal Weight | Thickness | Prime Applications | Key End-Use Projects |
|---|---|---|---|---|
| UD-200 | 200±10 g/m² | 0.111mm | Slab/beam flexural strengthening | Commercial building retrofits, factory floor upgrades |
| UD-300 | 300±10 g/m² | 0.167mm | Seismic column/wall shear retrofit | Highway bridge repairs, historic preservation |
